IPC9312LFW-AF28-2X4 – 2*2MP Lighthunter Dual-lens Network PTZ Camera

EGP10,400

Brand:
ogo of Uniview in red color, with a curved line over the "view" part
Uniview

IP CAMERA  — IPC9312LFW-AF28-2X4

Camera Type IP Camera, PTZ Camera
Camera – Usage Outdoor Camera
Connection type Wired ( Ethernet )
Resolution 2 Megapixel (2*2MP)
Lens Type Dual Lens, Fixed and Motorized Zoom
Focal Length Fixed and Motorized Zoom (2.8mm & 2.8-12mm)
Storage Options NAS (Network Attached Storage) Recording, NVR (Network Video Recorder) Recording, SD Card Recording
Smart Features 4X Optical Zoom, Built-in Dual Mic, Dual-lens Integration, LightHunter Technology, Smart Intrusion Prevention, Two-Way Audio
Power Supply PoE
Ingress Protection Rating (IP) IP66



















  •  Delivery & Return

    Delivery

    Our business days are Saturday to Thursday only, weekends and holidays are not included. Varies depending on delivery option chosen Home Delivery: Delivery time starts from the day you place your order to the day one of our delivery assistants first attempts to deliver it to you Store Pickup: Pickup time starts from the day you place your order until you receive our call to pick up your order from your chosen store.

    Return

    If the customer wishes to return or exchange the product, he can do so within 30 days from the date of purchase, as follows:

      Refunds will only be made through the original payment method. Attach the original purchase invoice.
    • The product must be in its original condition with the closure of the manufacturer *The customer can recover the value he paid as recorded and specified in the sales invoice. *The customer has the right to exchange one item for another with the same value mentioned in the invoice.
    • In the event of a manufacturing defect, a report will be submitted from the agent.

    Help

    Give us a shout if you have any other questions and/or concerns. Email: online@carniavl4trading.com Phone: (+201203300779)
  •  Ask a Question
  ... people are viewing this right now

  Share
Guaranteed Safe CheckoutTrust

The IPC9312LFW-AF28-2X4 is a high-performance dual-lens PTZ network camera that integrates both a fixed and a PTZ camera into one device, offering detailed and wide-angle views under a single IP address. Equipped with two 2MP CMOS sensors, the camera delivers 1920×1080 resolution at 25fps for both channels, ensuring detailed and clear imagery. The 4X optical zoom of the PTZ channel allows for closer inspection of distant subjects. Lighthunter technology guarantees excellent low-light performance, while the 120dB Optical WDR provides balanced images in challenging lighting conditions. The camera includes built-in microphones and a high-power speaker for enhanced two-way audio, making it ideal for scenarios where communication is crucial. With Smart Intrusion Prevention, the camera can efficiently classify and detect humans, vehicles, and other objects, reducing false alarms. Designed for flexibility, it supports both ceiling and wall mounts.

Key Features Include:

  • Dual-lens Integration: Combines a fixed and PTZ camera under one IP for wide and detailed coverage.
  • High-Quality Imaging: 2MP resolution with Lighthunter technology for enhanced low-light performance.
  • Optical Zoom: PTZ channel offers 4X optical zoom for close-up views.
  • Ultra 265, H.265, H.264, MJPEG: Efficient video compression for reduced bandwidth and storage usage.
  • 120dB Optical WDR: Delivers clear images in scenes with bright and dark areas.
  • Smart Intrusion Prevention: Reduces false alarms with human, vehicle, and non-vehicle classification.
  • Two-Way Audio: Equipped with 2 microphones and a high-power speaker for clear communication.
  • Flexible Mounting: Supports both ceiling and wall mount installations.
Specification IPC9312LFW-AF28-2X4
Camera
Sensor 1/2.8", 2MP CMOS
Minimum Illumination Color: 0.002 lux (F1.6, AGC ON), 0 lux with IR
Day/Night IR-cut filter with auto switch (ICR)
Shutter Auto/Manual, 1 ~ 1/100000s
WDR 120dB Optical WDR
S/N Ratio >52dB
Lens
Lens Type (Panorama) 2.8mm@F1.6
Lens Type (Detail) 2.8~12mm@F1.6, AF automatic focusing and motorized zoom
Optical Zoom (Detail) 4X
Iris Fixed aperture
Field of View (H) 102.4° (Panorama) / 106.6° ~ 30.6° (Detail)
Field of View (V) 54.9° (Panorama) / 56.5° ~ 17.4° (Detail)
Field of View (D) 133.1° (Panorama) / 138.6° ~ 37.6° (Detail)
DORI Distance
Detect (m) 43.4m (2.8mm lens), 162.9m (12mm lens)
Observe (m) 17.4m (2.8mm lens), 65.2m (12mm lens)
Recognize (m) 8.7m (2.8mm lens), 32.6m (12mm lens)
Identify (m) 4.3m (2.8mm lens), 16.3m (12mm lens)
Illuminator
IR Range Up to 10m (Panorama), Up to 50m (Detail)
Warm Light Range N/A (Panorama), Up to 10m (Detail)
Wavelength 850nm
Light On/Off Control Auto/Manual
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
Frame Rate Main Stream: 1080P (1920x1080) @ 25fps
Sub Stream 720P (1280x720) @ 25fps
Video Bitrate 128 Kbps ~ 16 Mbps
ROI Up to 8 areas
OSD Up to 4 OSDs
Privacy Mask Up to 24 areas, 4 per scene
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Noise Reduction 2D/3D DNR
Smart IR Supported
Flip Normal/Flip Vertical/Horizontal/180°
HLC/BLC Supported
Defog Digital Defog
Events
Detection Motion Detection, Audio Detection
General Functions Watermark, IP Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Audio
Audio Compression G.711U, G.711A
Two-Way Audio Supported (2 built-in microphones, high-power speaker)
Audio Bitrate 64 Kbps
Storage
Edge Storage Micro SD up to 256 GB
Network Storage ANR
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS
Compatible Integration ONVIF (Profile S, G), API, SDK
Security Password protection, Strong password, HTTPS, TLS 1.2
Pan & Tilt
Pan Range 0° ~ 345°
Tilt Range -10° ~ 100°
Pan/Tilt Speed 1°/s ~ 50°/s (tilt), 1°/s ~ 40°/s (pan)
Presets 256
Home Position Supported
General
Power DC 12V, PoE+ (IEEE 802.3at), Max Power: 16W
Dimensions (L×W×H) Wall Mount: Φ134 x 192 x 302mm, Ceiling Mount: Φ134 x 154 x 363mm
Weight 1.03kg
Ingress Protection IP66
Surge Protection 2KV
Working Environment -20°C ~ 60°C, ≤95% RH
The IPC9312LFW-AF28-2X4 is a versatile dual-lens PTZ network camera, combining a wide-angle fixed camera and a PTZ camera with 4X optical zoom. With Lighthunter technology, it ensures outstanding performance in low-light environments, while the 120dB WDR ensures image clarity in high-contrast scenes. Featuring built-in microphones and a high-power speaker, this camera also supports two-way audio, ideal for both surveillance and communication. Designed for flexibility, it supports both ceiling and wall mount installations and is rated IP66 for outdoor use.
Camera Type

IP Camera, PTZ Camera

Camera - Usage

Outdoor Camera

Connection type

Wired ( Ethernet )

Resolution

2 Megapixel (2*2MP)

Lens Type

Dual Lens, Fixed and Motorized Zoom

Focal Length

Fixed and Motorized Zoom (2.8mm & 2.8-12mm)

Storage Options

NAS (Network Attached Storage) Recording, NVR (Network Video Recorder) Recording, SD Card Recording

Smart Features

4X Optical Zoom, Built-in Dual Mic, Dual-lens Integration, LightHunter Technology, Smart Intrusion Prevention, Two-Way Audio

Power Supply

PoE

Ingress Protection Rating (IP)

IP66
